Architecture Supplies

Cleanroom Enclosures

Cleanroom & Containment
Cleanroom Enclosures

Supplied by

  • Senneca

About

  • Senneca cleanroom doors, wall systems and enclosures for mission critical environments, with flush surfaces, coved corners, sealed glazing and gasketed frames that hold a pressure differential. Every joint is detailed so the envelope can be wiped down and does not shed particles into the classified space.

Application

Used in pharmaceutical production, medical device assembly, semiconductor fabs, hospital compounding rooms and laboratory containment suites. The doors are part of the pressure cascade, not just an opening: leakage across a door set directly reduces the differential that keeps the classified space clean, so gasket and closer performance are validated with the room rather than certified separately.

Standards & Reference 6 cited

  • ISO 14644-1

    Cleanroom air cleanliness classification by particle concentration, which is where the ISO Class 5, 7, 8 designations come from.

  • ISO 14644-3

    The test methods used to verify a cleanroom performs to its classification once installed.

  • ASTM E84

    Surface burning characteristics: the flame spread index and smoke developed index a material is classified by. Class A is the usual requirement in an occupied building.

Also citedISO 14644-4EU GMP Annex 1USP <797>

Request for quotation

Get a price for this item

Send the quantity and the project. Our sales engineers reply with a quotation, usually within one working day.
